"DEVELOP & MAKE & SALES"
|
||
Precise saw carriage, load bearing in chrome-plating rail, glide smooth steady, around the adjustment is convenient, is equipped with the cushion, the drinking die precision is high, non-fragments production.
The optical fiber switch
Optical fiber switch uses the ohm dragon high sensitivity light to weave the combination to retun the zero point immediately not at the appointed time in the plate illunination and to save the trolley time of travel easy to operaate.
Depends on the material air cylinder
To be possible to save after the space and attaches adjusts the thrustplate may make the manual trimming depends
on the size, the convenient plate turnover cuts the tangent.
The fluctuation floor (Optional)
Function of the floor, the simplicity of operator, easily moves the plate and saves the manpower, what but common machine with is wind drum machine this department uses the import the high-pressures air blower to float adove power ratio wind drum machine high one time.
The key type dust cover (Optional)
To use imports the PP plastic wear-resisting revertex not to be easy to damage bright and clean dustproof to vacuum easily high.
Flowing tubing head pressure lift table
Model: HH-48-3T
Work table size: 1200 x 2400 mm
Most treamendous pressure: 3T
SPECIFICATIONS |
MODEL | HH-PRO-8/HH-PRO-8-S | HH-PRO-10/HH-PRO-10-S | HH-PRO-12/HH-PRO-12-S |
Maximum depth of cut | 80 mm | 80 mm | 80 mm |
Maximum length of cut | 2650 mm |
3250 mm | 3850 mm |
Main saw blade diameter | 355 mm | 355 mm | 355 mm |
Main saw spindle diameter | 30 mm | 30 mm | 30 mm |
Main saw spindle rotational speed | 4800 rpm | 4800 rpm | 4800 rpm |
Vice-saw blade diameter | 160 mm | 160 mm | 160 mm |
Vice-saw blade spindle diameter | 30 mm | 30 mm | 30 mm |
Vice-saw spindle rotational speed | 6500 rpm | 6500 rpm | 6500 rpm |
Saw carriage speed | 0-52 m/min | 0-52 m/min | 0-52 m/min |
Saw carriage backlash speed | 0-52 m/min | 0-52 m/min | 0-52 m/min |
Main saw blade motor | 15 HP | 15 HP | 15 HP |
Saw carriage drive motor | 3 HP | 3 HP | 3 HP |
Working air pressure | 5-6kgs/cm2 | 5-6kgs/cm2 | 5-6kgs/cm2 |
Table height from floor | 820mm | 820mm | 820mm |
Machine dimensions | 4900 x 3400 x 1525 mm | 5790 x 3400 x 1525mm | 6654 x 3400 x 1525mm |
Net weigh | HH-PRO-8 (2200/2380 kg) HH-PRO-8-S (2300/2480kg) |
HH-PRO-10 (2600/3180kg) HH-PRO-10-S (2700/3280kg) |
HH-PRO-12 (3000/3380kg) HH-PRO-12-S (3100/3480kg) |
* Specifications and design characteristics are subject to change without prior. |
